Authenticate Zoho CRM in PHP

Last update

20 min.
  1. SDK installation
  2. SDK configuration
  3. Access and Refresh Token generation
  4. What's next?





Before jumping into manual, you can clone ready boilerplate Zoho CRM implemention for:

Laravel

https://github.com/blowstack/zoho-crm-laravel.git

or

Symfony

https://github.com/blowstack/zoho-crm-symfony.git





SDK Installation



Install the official Zoho SDK for PHP.

Open the console, go to the folder where your app resides and type the following command:

composer require zohocrm/php-sdk



Before using API you are obliged to register and use a Zoho client.

It's an easy process just go to the Zoho console and login into your account.

There are multiple ways to register a new client. Druing this post we will stick to self client.



Zoho CRM OAuth Self Client option



Self client is enough to integrate Zoho CRM system in a way that your web/mobile app handle all the communication without need to authenticate other users. In other words your app will be the client / user. This will enable you to fully use all the available modules and functionality through backend.

After registering a client there will be two tabs, don't fill the form in Generate Code tab yet. We will only need automatically generated data from the Client Secret tab at the moment.

Having Client ID and Clients secret we can proceed to the SDK configuration stage.





SDK Configuration



First you have to consider where you want to keep your authorisation tokens. There are two possibilities:

  • in file (recomended)
  • in database



SECURITY NOTICE

For security reasons I strongly discourage you to save tokens in a database thus we will cover only persistence in a file.



To proceed we need to create a file with name zcrm_oauthtokens.txt where all the tokens will be stored.



Symfony & Laravel

Put crm_oauthtokens.txt into the config folder and then into a Zoho folder (you need to create it first).



Make a new controller for token generation and name it ZohoOauthController.

Inside the controller create a new array with config. Just copy & paste client id and client secret from the newly registered client (Client Secret tab).



Zoho CRM OAuth Client Secret tab



Redirect uri has to be filled but it can be a dummy url as we use self client and it's not realy needed here. For currentUserEmail field pass your email address for the Zoho developer console. In token persistence path pass the aboslute path to the crm_oauthtokens.txt file.



$configuration = [
	"client_id"					=> 	client_id,
	"client_secret"				=> 	client_secret,
	"redirect_uri"				=>	redirect_url,
	"currentUserEmail"			=>	user_email,
	"token_persistence_path"	=>  path_to_crm_oauthtokens.txt
];





Symfony implementation




bin/console make:controller



  • ZohoOauthController.php



<?php

namespace App\Controller;

use Symfony\Bundle\FrameworkBundle\Controller\AbstractController;
use Symfony\Component\Routing\Annotation\Route;
use zcrmsdk\crm\setup\restclient\ZCRMRestClient;
use zcrmsdk\oauth\ZohoOAuth;

class ZohoOauthController extends AbstractController
{
  /**
   * @Route("/admin/zoho/oauth/{grant_token}", name="admin_zoho_oauth_generate")
   * @param $grant_token
   */
    public function generateTokens($grant_token)
    {

      $configuration = [
       "client_id"			=> 	'1000.A17M9ZGQRZEFDIFEM9TQ378I3NF9PH',
       "client_secret"		=> 	'b76bd9cb9e10d4982762c7c1812ded35cb54d5404f',
       "redirect_uri"		=>	'http://dummy_address',
       "currentUserEmail"	=>	'dev@blowstack.com',
       "token_persistence_path" =>"/home/blowstack/Projects/boilerplates/zoho_crm_symfony/config/Zoho"
      ];

      $result = 'failed';

      try {
        ZCRMRestClient::initialize($configuration);
        $oAuthClient = ZohoOAuth::getClientInstance();
        $grantToken = $grant_token;
        $oAuthTokens = $oAuthClient->generateAccessToken($grantToken);
        $result = 'success';
      }
      catch (\Exception $exception) {
        $result = $exception;
      }


        return $this->render('zoho_oauth/index.html.twig', [
            'result' => $result,
        ]);
    }
}



  • zoho_oauth/index.html.twig




{% extends 'base.html.twig' %}

{% block title %}Zoho Oauth{% endblock %}
{% block body %}

	<h3 style="text-align: center">{{ result }}</h3>

{% endblock %}





Laravel implementation




php artisan make:controller ZohoOauthController --invokable



  • ZohoOauthController.php



<?php

namespace App\Http\Controllers;

use Illuminate\Http\Request;
use Illuminate\View\View;
use zcrmsdk\crm\setup\restclient\ZCRMRestClient;
use zcrmsdk\oauth\ZohoOAuth;

class ZohoOauthController extends Controller
{
    /**
     * Handle the OAuth for Zoho.
     * @param  string  $grant_token
     * @return \Illuminate\Contracts\Foundation\Application|\Illuminate\Contracts\View\Factory|View
     */
    public function __invoke(string $grant_token)
    {
        $configuration = [
            "client_id"			=> 	'1000.A17M9ZGQRZEFDIFEM9TQ378I3NF9PH',
            "client_secret"		=> 	'b76bd9cb9e10d4982762c7c1812ded35cb54d5404f',
            "redirect_uri"		=>	'http://dummy_address',
            "currentUserEmail"	=>	'dev@blowstack.com',
            "token_persistence_path" =>"/home/blowstack/Projects/boilerplates/zoho_crm_laravel/config/Zoho"
        ];

        try {
            ZCRMRestClient::initialize($configuration);
            $oAuthClient = ZohoOAuth::getClientInstance();
            $grantToken = $grant_token;
            $oAuthTokens = $oAuthClient->generateAccessToken($grantToken);
            $result = 'success';
        }
        catch (\Exception $exception) {
            $result = $exception;
        }

        return view('zoho_oauth', ['result' => $result]);
    }
}



  • routes/web.php



Route::get('zoho/oauth/{grant_token}', 'ZohoOauthController');



  • zoho_oauth.blade.php



<!DOCTYPE html>
<html lang="{{ str_replace('_', '-', app()->getLocale()) }}">
    <head>
        <meta charset="utf-8">
        <meta name="viewport" content="width=device-width, initial-scale=1">
        <title>Zoho OAuth</title>
    </head>
    <body>
        <h3 style="text-align: center">{{ $result }}</h3>
    </body>
</html>





Access and Refresh Token generation



The Controller and the route has been set up so it's time to generate our tokens but first you need a grant token in order to generate other tokens like access token and refresh token. The good news is it's only a one time process so let's finish it up now!  Get back to the zoho developer console.



Zoho CRM OAuth Grant Token Geenration



There is Generate Code tab in self client option . Fill the form in the following way.

Scope*

ZohoCRM.modules.ALL, Aaaserver.profile.Read

(there can't be spaces between commas separating scope names!)

Time duration

3 minutes

Scope description

Whatever but is has to be filled out.



*reconsider this scope on the production environment. Those two give you minimal access needed to generate tokens and make all API calls related to modules which should be enough in most cases though.



Copy the generated grant token and paste it to the url you-rapp-address/zoho/oauth/{grant-token}.

If all went well your previously created file zcrm_oauthtokens.txt will be filled with data and you should see a success text. That's all, for now. You can finally forget about the whole process of generating tokens. It will be 100% handled by the SDK without your assitance. Congrants!



What's next?



You are ready to use the API!

But you can do one more thing related to the code. Namely you can refactor it by creating a zoho service which will become truly useful when you start using the API heavily in different part of your app. It will take 2 additional minutes now but it will save you a lot of time in the future so it’s definitely worth doing it.



Symfony implementation




In the src/Service create a new class named ZohoCRM in that way.

<?php


namespace App\Service;


use zcrmsdk\crm\setup\restclient\ZCRMRestClient;
use zcrmsdk\oauth\ZohoOAuth;

class ZohoCRM
{

    private $configuration;

    public function __construct(array $config_values) {

        $this->configuration = [
            "client_id" => $config_values['client_id'],
            "client_secret" => $config_values['client_secret'],
            "redirect_uri" => $config_values['redirect_uri'],
            "currentUserEmail" => $config_values['currentUserEmail'],
            "accounts_url" => "https://accounts.zoho.com",
            "token_persistence_path" => $config_values['token_persistence_path'],
            "access_type" => "offline",
            "persistence_handler_class" => "ZohoOAuthPersistenceHandler"
        ];

        ZCRMRestClient::initialize($this->configuration);

    }


    public function generateAccessToken(string $grant_token): string {

        $configuration = $this->configuration;

        try {
            ZCRMRestClient::initialize($configuration);
            $oAuthClient = ZohoOAuth::getClientInstance();
            $grantToken = $grant_token;
            $oAuthTokens = $oAuthClient->generateAccessToken($grantToken);
            return 'success';
        } catch (\Exception $exception) {
            return $exception;
        }
    }

}



Then pass the config values into tha services.yaml file:

//services.yaml
parameters:
    zoho_crm:
        client_id: '1000.FT392KQV3WP8YMZ4A8L3PPJO40DRKH'
        client_secret: '676611b6b29038ab5d6cb82c2ae5bb2a7843cfb728'
        redirect_uri: 'http://dummy_address'
        currentUserEmail: 'dev@blowstack.com'
        token_persistence_path: '/home/blowstack/Projects/boilerplates/zoho_crm_symfony/config/Zoho'



And register your new service passing the config values:

//services.yaml
services:
 ...
    App\Service\ZohoCRM:
        arguments:
            $config_values: '%zoho_crm%'



Finally inject the new service into the controller and remove the old code. Notice that our controller became more readable and concise.

<?php

namespace App\Controller\admin;

use Symfony\Bundle\FrameworkBundle\Controller\AbstractController;
use Symfony\Component\HttpFoundation\Request;
use Symfony\Component\Routing\Annotation\Route;
use App\Service\ZohoCRM;

class ZohoOauthController extends AbstractController
{

     /**
     * @Route("/admin/zoho/oauth/{grant_token}", name="admin_zoho_oauth_generate")
     * @param ZohoCRM $zohoCRM
     * @param $grant_token
     * @return \Symfony\Component\HttpFoundation\Response
     */
    public function generateTokens(ZohoCRM $zohoCRM, $grant_token)
    {
        $result = $zohoCRM->generateAccessToken($grant_token);

        return $this->render('admin/zoho_oauth/index.html.twig', [
            'result' => $result,
        ]);
    }
}
